Ca Zn Stabilizer YC-313 For All Colors UL80/105℃ PVC Cables

Main Components:

Ca-Zn series organic complex. Based on high-grade calcium fatty acid and high-grade zinc fatty acid, it is compounded with high-performance heat-resistant additives, primary and secondary antioxidants, etc., and processed through a special composite technology.

Physical Properties:

Appearance: Light yellow to white powder; Specific Gravity: 1.5±0.1

Characteristics:

1. Environmentally friendly, complying with the requirements of RoHS, REACH, PAHS and NO-16P.
2. Excellent high-temperature resistance and heat aging resistance; no coking or blackening of products after aging.
3. Superior anti-precipitation performance when used in white, light-colored, colored, variegated and black PVC plastic materials and products.
4. Excellent color retention performance; there is almost no color difference in materials after long-term shutdown.
5. The products have bright and glossy appearance, with no discoloration or fading when placed.
6. Resistant to high shear, no sticking particles during air cutting, and supports full-speed operation of extrusion equipment.
7. Less material discharge and rubber discharge during wire extrusion, resulting in low material waste.
8. Good dispersibility, fast temperature rise during powder mixing, and no powder flying.

Applications:

Generally applicable to white, light-colored, colored, variegated and black PVC plastic materials and products.

1. Suitable for UL80/105℃ wires and cables, and computer peripheral wires.
2. Suitable for national standard HI-90 cable sheath materials.
3. Suitable for GB/T 12706 (equivalent to international standard IEC 60502) 90℃ standard, compatible with general power/control cables.

Usage and Dosage

1. Dosage: 5～6 PHR of the product per 100PHR resin

(Note: PHR refers to Parts Per Hundred of Resin)

Packaging and Storage

• Packaging: 25kg paper-plastic compound bag.
• Storage: Store in a cool, dry and well-ventilated place. It is advisable to use up the product within one year.

General Formula:

Notes:

1.Depending on the processing machine and formula, customers need to appropriately adjust the lubrication system.

2.In the formula system of relatively soft materials with a certain amount of chlorinated paraffin, reduce the dosage of stearic acid and PE wax, and test the precipitation performance.

3.TOTM is recommended as the plasticizer.
